HCA300(10°Down Angle) Marine Gearbox Main Data

HCA300(10°Down Angle) Marine Gearbox Main Data Featured Image
  • HCA300(10°Down Angle) Marine Gearbox Main Data


  • Min.Order Quantity: 1 unit
  • Supply Ability: 100 units per month

    • Product Detail

    Input speed

    1000-2500r/min

    Reduction ratio

    1.50、2.00、2.57

    Trans. capacity

    0.250kw/r/min

    2.95

    0.235kw/r/min

    Control way

    Electrically, push-and-pull flexible shaft

    Rated thrust

    40KN

    Center distance

    278mm

    L×W×H

    620×585×753mm

    Net weight

    370kg

    Flywheel

    SAE16 18 14

    Bell housing

    SAE0 1
