HCQ1601 Marine Gearbox Main Data
|
Input speed |
1600-2100r/min |
||
|
Reduction ratio |
3.04 |
Trans. capacity |
1.204kw/r/min |
|
3.24 |
1.0kw/r/min |
||
|
Control way |
Push-and-pull flexible shaft, electrically |
||
|
Rated thrust |
120KN |
||
|
Center distance |
370mm |
||
|
L×W×H |
1106×1230×1180mm |
||
|
Net weight |
1550kg |
||
|
Flywheel |
SAE21 18 |
||
|
Bell housing |
NO |
||
