Marine Gearbox D300A Main Data
|
Input speed |
1000-2500r/min |
||
|
Reduction ratio |
4 |
Trans. capacity |
0.257kw/r/min |
|
4.48 |
0.243kw/r/min |
||
|
5.05 |
0.221kw/r/min |
||
|
5.52、5.90 |
0.184kw/r/min |
||
|
6.56、7.06 |
0.147kw/r/min |
||
|
7.63 |
0.125kw/r/min |
||
|
Control way |
Push-and-pull flexible shaft, electrically, pneumatically |
||
|
Rated thrust |
60KN |
||
|
Center distance |
355mm |
||
|
L×W×H |
786×980×1041mm |
||
|
Net weight |
940kg |
||
|
Flywheel |
12V135、SAE18、16、14 |
||
|
Bell housing |
12V135、SAE0、1 |
||
